TR 430 A - Thermal Riflescope with Audio
Tax excluded. Shipping calculated at checkout
- 400×30012 μm Sensor Resolution
- 1950 yd Detection Range
- 35mm; F1.0 Focal length
- 1024x768 Display Resolution
The TR Series is a compact thermal imaging riflescope imagined with intuitive ergonomics, high shock resistance and a rugged and durable body.
The TR 430 A is equipped with a 35mm germanium lens and a 400x300 resolution thermal sensor with a 25mK NETD, it has a detection range of 1950 yards, and a base magnification of 3.3X.
Sensor | ||||
Type | Uncooled VOx Infrared Detector, 8 to 14μm | |||
Resolution | 400×300@12μm | |||
NETD | 25mK | |||
Frame rate | 50 Hz | |||
Lens | ||||
Objective lens | 35mm, F1.0 | |||
Field of view | 7.8°×5.9° | |||
FOV m@100m | 14×10 | |||
Magnification | 3.3x~13.2x | |||
Detection range | 1800m/1950yd | |||
Display | ||||
Display type | 0.39'' AMOLED 1024×768 | |||
Color palettes | White Hot, Black Hot, Red Hot, Green Hot, Iron Red, Blue Hot, Sepia | |||
Eyepiece | Eye relief: 48 mm; Diopter ± 4; Zoom: 14x | |||
Hardware | ||||
WIFI | 2.4G | |||
Interface | USB Type-C | |||
Others | Microphone, Bluetooth | |||
System | ||||
Recording function |
Photo/Video (Audio recording included) |
|||
Memory capacity | 32GB | |||
Power | ||||
Battery type | Single, replaceable 18650 battery | |||
Operating time | 8 hours | |||
Environmental | ||||
Operating temp. | -30°C to 50°C / -22°F to +122°F | |||
Shock | 800G at 1ms half sine pulse (as per IEC60068-2-27) | |||
Encapsulation | IP67 | |||
Physical | ||||
Weight (g/oz) | 565/19.93 | |||
Size (mm/in) | 206×89×66/8.11×3.50×2.60 | |||
Standard | Device, Quick-release scope mount, Type-C cable, 5V2A adapter (US, Britain, Australia and Europe), 18650 battery, Battery charger, Lens cover, Eye mask, Quick start guide, Warranty card | |||
Optional | 18650 battery, Dovetail guide, Bluetooth remote control, Laser rangefinder |
The TR Series of thermal scopes were specifically designed to be compact and lightweight, but they come with all the features that you can expect, which include: built-in recording and picture capture capabilities, Wi-Fi hotspot, 8X digital zoom, TargetIR app compatibility for storing and sharing images and videos, constant OTA upgrades, IP67 protection rating, 8 hours of battery life.
With a variety of models, whether you prioritize extreme thermal sensitivity, high base magnification, or a balanced combination of both, there’s a TR model tailored to meet your specific requirements.
As always with Guide Sensmart, we are prouf to offer a 10-year warranty on your optic and its thermal sensor. We trust our products more than anything else and are the only ones to offer this kind of warranty. With a Texas-based repair center, you can rest assured that you'll get your product back within a week.
Product Features
400x300 / 12μm
25mK
50 Hz
35mm, F1.0
7.8°×5.9°
3.3x~13.2x
1950yd
8 Hours (18650 Battery)
The updated TR Series uses high-quality 12µm thermal imaging detectors with 400×300 thermal resolution and 25mK NETD to offer an exceptionally sharp image and excellent thermal sensitivity in all weather conditions.
Connect the device to TargetIR Ballistics APP (Android or iOS) to set bullet and weather parameters, then transmit the data to the device for ballistic calculation, and achieve high-precision shooting easily.
Simply mount the device onto the quick-release scope mount, then tighten the locking lever, and the TR Series can be easily and securely mounted without any other rifles.
The photo and video function allow users to capture and share wonderful moments anytime, and integrates a built-in microphone for recording sound.
The full-color 0.39-inch HD OLED display with 1024×768 pixels delivers sharp, richly contrasted, and vivid images that capture every moment in perfect detail.
The updated TR Series uses high-quality 12µm thermal imaging detectors with 400×300 thermal resolution and 25mK NETD to offer an exceptionally sharp image and excellent thermal sensitivity in all weather conditions.
Connect the device to TargetIR Ballistics APP (Android or iOS) to set bullet and weather parameters, then transmit the data to the device for ballistic calculation, and achieve high-precision shooting easily.
Simply mount the device onto the quick-release scope mount, then tighten the locking lever, and the TR Series can be easily and securely mounted without any other rifles.
The photo and video function allow users to capture and share wonderful moments anytime, and integrates a built-in microphone for recording sound.
The full-color 0.39-inch HD OLED display with 1024×768 pixels delivers sharp, richly contrasted, and vivid images that capture every moment in perfect detail.
1950 yd
High-precision detection range
External Laser Range Finder
With an external laser range finder, the TR series can achieve 600 meters/ 656 yard of accurate distance measurement for quick target searching, allowing for easy and fast connection thanks to the bluetooth feature.
