TB 630 Thermal Clip-On 640X512 35mm 20mK

Name: TB 630 Thermal Clip-On 640X512 35mm 20mK
Brand: Guide IR Thermal USA
SKU: TB630
Price: 3189.00 USD
Availability: InStock

$3,189.00

Tax excluded. Shipping calculated at checkout

COMPACT THERMAL CLIP-ON

640×512@12μm Sensor Resolution
1950 yd Detection Range
35mm; F1.0 Focal Length
20Mk NETD
0.39'' AMOLED Display 1920×1080
12 Hours Battery Life (2x 18650 batteries)

Description

Sensor
Type	Uncooled VOx Infrared Detector, 8 to 14μm
Resolution	640×512@12μm
NETD	20mK
Frame rate	50Hz

Lens
Objective lens	35mm, F1.0
Field of view	12.5°×10.0°
FOV m@100m	22×17
Magnification	1x
Detection range	1800m/1950yd

Display
Display type	0.39'' AMOLED 1920×1080
Color palettes	White Hot, Black Hot, Red Hot, Green Hot, Iron Red, Blue Hot, Sepia
Eyepiece	Eye relief: 20mm; Zoom: 9.5x

Hardware
WIFI	2.4G, 5G
Interface	USB Type-C (Power supply/USB2.0)
Others	Microphone, Bluetooth

System
Recording function	Photo/Video (Audio recording included)
Memory capacity	64GB

Power
Battery type	2 replaceable 18650 batteries
Operating time	10 hours

Environmental
Operating temp.	-20°C to 50°C / -4°F to +122°F
Recoil Rating	.300 Win Mag
Encapsulation	IP68

Physical
Weight (g/oz)	440/15.52
Size (mm/in)	128×79×79/5.04×3.11×3.11
Standard	A device, Battery charger, 18650 battery×2, 5V2A adapter (US, Britain, Australia and Europe), USB Type-C cable, Quick use guide, Warranty card
Optional	18650 battery, Bluetooth remote control, Cover ring adapter

Quantity:

Full-HD 1920x1080 AMOLED display

The eyepiece features a 1920x1080 high-definition AMOLED screen allowing for a visual experience with vibrant colors and excellent image quality. This significantly enhances the comfort of observation.

12μm advanced thermal detector, NETD<25mK

By utilizing a highly sensitive IR detector with a NETD<25mK, even the slightest temperature differences can be distinguished, resulting in sharper and clearer imaging.

12-hour Battery Life

Thanks to two replaceable 18650 batteries, experience wild adventures with power energy consumption, lightweight design, and enduring performance.

Compact design lightweight and portable

A magnesium alloy housing paired with a compact design, light weight but powerful

User Manual - TB SERIES

Download your full manual user here

TB USER MANUAL

Accessories

Rusan ARTA435 - Quick-release bell-mount adapter for Thermal Clip-On

$169.00

Rusan MAR - Quick-release bell-mount adapter for Thermal Clip-On

$199.00

Bluetooth controler for TA Clip-ON - Guide IR Thermal USA

Bluetooth controler for TB & TA Series - Thermal Clip-On

$89.00

QD 1.5" pica mount for Thermal Clip-On TB

$180.00

General
	TB 630 Thermal Clip-On 640X512 35mm 20mK$3,189.00	TB 430 Thermal Clip-On 400X300 35mm 25mK$2,599.00	TB 630 LRF Thermal Clip-On 640X512 35mm 20mK Laser Rangefinder / QD Mount$3,299.00	TB 650 LRF PRO Thermal Clip-On 640X512 50mm 18mK Laser Rangefinder$3,849.00	TB 1250 LRF PRO Thermal Clip-On 1280X1024 50mm 18mK Laser Rangefinder$5,549.00
Thermal Sensor Resolution	640X512 @20mK	400×300 @25mK	640x512 @20mK	640x512 @18mK	1280x1024 @18mK
Objective Lens	F35/1.0	F35/1.0	F35/1.0	F50/1.0	F50/1.0
Detection Range	1950yd	1950yd	1950yd	2800yd	2800yd
Laser Rangefinder	No	No	Yes	Yes	Yes
Display Size	0.39'' AMOLED 1920×1080	0.39'' AMOLED 1920×1080	0.39'' AMOLED 1920×1080	0.39'' AMOLED 1920×1080	0.39'' AMOLED 1920×1080
Weight	15.5 Oz	15 Oz	15.8 Oz	20.5 Oz	21.7 Oz
Mount Type	Optional Rusan Bell or Pica Mount	Optional Rusan Bell or Pica Mount	Integrated QD Picatinny Mount	Optional Rusan Bell or Pica Mount	Optional Rusan Bell or Pica Mount
Battery Life	12h	12h	6h	9h	6h
Battery Type	18650 ×2 Battery (External)	18650 ×2 Battery (External)	18650 ×1 Battery (External)	18650 ×2 Battery (External)	18650 ×2 Battery (External)
