TB1260 PRO Apex
Thermal Clip-on with In-Lens LRF
Tax excluded. Shipping calculated at checkout
- 1280x1024 Apex Vision Thermal Sensor
- 0.5'' AMOLED 1600x1200: Ultra-Wide Display
- 3500yd Detection Range
- 1630yd In-Lens Laser Rangefinder
- 6 hours Battery Life, Rechargeable 18650 Battery
| Sensor | ||||
|---|---|---|---|---|
| Core Technology Item | Equipped with full ApexVision S1 system architecture: Detector ApexCore S1 + Platform Nexus 1.0 + Algorithm Hyper-Light 2.0 | |||
| Type | Uncooled VOx Infrared Detector, 8 to 14μm | |||
| Resolution | 1280×1024@12μm | |||
| NETD | 15mK | |||
| Frame rate | 50Hz | |||
| Lens | ||||
|---|---|---|---|---|
| Objective lens | 60mm, F1.0 | |||
| Field of view | 14.6°×11.0° | |||
| FOV m@100m | 25×19 | |||
| Magnification | 1x | |||
| Detection range | 3500yd | |||
| Focus | Manual | |||
| Display | ||||
|---|---|---|---|---|
| Display type | 0.5'' AMOLED 1600×1200 | |||
| Color palettes | White Hot, Black Hot, Red Hot, Green Hot, Iron Red, Blue Hot, Sepia | |||
| Eyepiece | Eye relief: 20mm | |||
| Hardware | ||||
|---|---|---|---|---|
| Laser rangefinder | 1300yd | |||
| WIFI | 2.4G, 5G | |||
| Interface | USB-C (Power supply/USB2.0) | |||
| Others | Microphone, Bluetooth | |||
| System | ||||
|---|---|---|---|---|
| Recording function | Photo/Video (Audio recording included) | |||
| Memory capacity | 64GB | |||
| Power | ||||
|---|---|---|---|---|
| Battery type | Replaceable 18650 ×2 Battery | |||
| Operating time | 6 hours | |||
| Environmental | ||||
|---|---|---|---|---|
| Operating temp. | -4°F to +122°F | |||
| Shock | 6000J | |||
| Encapsulation | IP68 | |||
| Physical | ||||
|---|---|---|---|---|
| Weight (oz) | 26.10 | |||
| Size (in) | 6.38×3.82×4.02 | |||
| Standard | Device, Carry Bag, Accessory Bag, Lint-Free Cloth, Battery Charger, 18650 Battery ×2, USB-A to USB-C Cable, Quick Start Guide, Warranty Card | |||
| Optional | Bluetooth Remote Control, Adapter Ring, 18650 Battery | |||
This item is currently out of stock and will ship in November 2026. You can pre-order now or contact us at contact@guideir-thermal.com for more information.
TB1260 PRO Apex Thermal Clip-On 1280x1024 60mm 15mK In-Lens LRF
Sale price$6,299.00
|  | |
|---|---|---|
| General | ||
Thermal Sensor Resolution |
|
|
Objective Lens |
|
|
Detection Range |
|
|
Laser Rangefinder |
|
|
Display Size |
|
|
Weight |
|
|
Battery Life |
|
|
Battery Type |
|
|
1280x1024
Thermal Sensor
Why using a thermal clip-on?
A thermal clip-on offers unmatched versatility and cost-efficiency compared to a dedicated thermal scope. Clip-ons attach directly to your existing daytime optic, allowing you to switch seamlessly between thermal and traditional viewing without re-zeroing or carrying extra gear.
Whether you’re scanning for game at dawn or navigating low-light conditions, a thermal clip-on like the new Guide TB1260 PRO Apex delivers performance, convenience, and value
